Single S 1600mm Non Woven Production Line

  • Single S 1600mm Non Woven Production Line
  • Single S 1600mm Non Woven Production Line
  • Single S 1600mm Non Woven Production Line
  • Single S 1600mm Non Woven Production Line

Single S 1600mm Non Woven Production Line

    Unit Price: 330000~730000 USD
    Min. Order: 1 Set/Sets
    Packaging: The wooden case
    Brand: YIHONGTONG
    Transportation: Ocean
    Place of Origin: China
    Port: SHANGHAI

Product Description

1600MM melt blown cloth machine, melt blown cloth production line, we specialize in the production of mask melt blown non-woven fabric equipment. PP melt blown cloth production line is used to produce PP melt blown cloth. The melt-blown cloth production line uses polypropylene pellets as raw materials and undergoes processes such as high-temperature melting, spinning, fiber formation, fiber cooling, and winding to produce melt-blown non-woven fabrics. The automatic feeder automatically sucks in the drawing-grade polypropylene and sends it to the extruder, and the extruder heats and melts the PP particles to a liquid state. Roots blower or air compressor and compressed air from the air storage tank are sent to the oven for heating. The hot air uses the pressure to spray the molten polypropylene material from the nozzle to form filaments (the nozzle contains hundreds of small holes) ), the sprayed filaments reach the receiving equipment horizontally, and then they can be wound and unwinded.
MODEL
UNIT
YH-S1600
YH-S2400
YH-S3200
YH-S4200
Effective Fabric Width
mm
1600
2400
3200
4200
Original Fabric Width
mm
1850
2650
3510
4510
Daily Capacity (based on 30gsm)
ton
4
7
10
12
Max Diameter of Fabric In Roll
mm
1200
2000
2000
2000
Monofiilament Fineness
denier
1.5~2.0
1.5~2.0
1.5~2.0
1.5~2.0
GSM of Fabric
g/m2
10~200
8~150
10~150
10~150
Max Production Speed
m/min
150
150
150
150
Process Production Speed
m/min
15~150
15~150
15~150
15~150
Total Installation Power
kw
380
450
500
550
Machiney Dimension(L*W*H)
meter
15*8*11
15*12*11
15*14*11
15*16*11
Installation Site Iimension(L*W*H)
meter
21*15*12
21*17*12
21*19*12
21*22*12
Total Net Weight Of Machine(appox)
ton
68
75
85
95


the company

PUYISEN


PUYISEN is one of the leading manufacturer of complete nonwoven line in China. We focus on manufacture,sale and research & development of nonwoven lines. We started working on manufacture of nonwoven lines in year 2006.
We mainly manufacture spunbond nonwoven lines such as single beam(S line), double beams(SS line) and three-beams(SSS line), spunmelt (spunbond & meltblown) nonwoven lines such as SMS,SSMS,SMMS. The main width are 1600mm,2400mm,3200mm,
4200mm.
The grammage range will be from 10gsm to 80gsm with high technical performance.

Meanwhile,we also provide the the related slitting machine, treated machine,perforated machine,stretch film wrapping machine, 2/3 layer laminated machine, PE coating machine etc. They are widely application to the hygiene,medical health care,industrial, agriculture, furniture,household,building, Geotextile and filtration fields. Trust us, we are on the way to become your honest business partner!

Changzhou Puyisen Machinery Technology Co., Ltd.



Changzhou Puyisen Machinery Technology Co., Ltd. is located in Wujin District, Changzhou, a long-standing and culturally rich Yangtze River Delta Economic Zone. It is close to Shanghai and Nanjing, with superior geographical location, good investment environment and fast and convenient transportation. Our company is specialized in manufacturing and selling, polypropylene spunbond non-woven fabric production equipment, polyester filament needle punched non-woven fabric production line, meltblown non-woven fabric production equipment. Pu Yisen Technology has independently developed and innovated, and successfully developed non-woven fabric punching machines, plastic film ultra-micro punching equipment and hot-pressing equipment, as well as air-permeable and water-impermeable ultra-micro hole punching equipment for packaging materials.
